الوصف
شبكة بإطار
الكتلة: 72 كجم.
المواد: الحديد الزهر – FGL 250.
طلاء: طلاء أسود مضاد للصدأ.
| Dimensions (mm) | Force (KN) | Masse (Kg) | |||||
| Type | A x A | H | O x O | Classe | Cadre | Grille | |
| 300X300 | 340 X 340 | 35 | 272 | A 15 | 9 | 8 | |
| 400X400 | 437 X 437 | 40 | 370 X 370 | B125 | 12 | 14 | |
| 445 X 445 | 50 | 366 X 366 | D400 | 17 | 22 | ||
| 500X500 | 537 X 537 | 40 | 466 X 466 | B125 | 12 | 22 | |
| 540 X 540 | 58 | 464 X 464 | D400 | 21 | 40 | ||
| 600X600 | 644 X 644 | 45 | 558 X 558 | B125 | 25 | 40 | |
| 650 X 650 | 75 | 560 X 560 | D400 | 35 | 55 | ||
| 700X700 | 750 X 750 | 55 | 660 X 660 | B125 | 57 | 56 | |
| 770 X770 | 85 | 630 X630 | D400 | 80 | 100 | ||
